Introduction:
SLK-R690-4G-A4 is a multi-functional wireless Vehicle 4G CPE Router product with high-performance 4-core CPU, high power WiFi6, and integration of cellular 4G network. Supports 5x 1000M Ethernet ports, which can be configured as LAN/WAN ports, you can choose DC48V POE power out version,2X2 MIMO 2.4g /5.8G WIFI6, etc. It also adopts wide temperature, wide voltage input and EMC test with electromagnetic compatibility.
Has been widely used in the Internet of things industry chain of M2M industry, such as self-service terminals, smart grid, smart transportation, smart home, financial, mobile POS terminals, supply chain automation, industrial automation, intelligent buildings, fire control, public security, environmental protection, meteorology, digital medical treatment, telemetry, agriculture, forestry, water, coal, petrochemical and other fields.
Features:
●Qualcomm Quad-core CPU/ 1.8GHz,8Gb DDR3,4GB eMMC
●802.11ac mode: PHY rate: 866.7 Mbps (5 GHz) and 400 Mbps (2.4 GHz)
or proprietary PHY rate: 1083 Mbps (5 GHz) and 500 Mbps (2.4 GHz)
●802.11ax mode: PHY rate: 1201 Mbps (5 GHz) and 573.5 Mbps (2.4 GHz)
●Wi-Fi supported IEEE802.11ac, IEEE802.11ax
●Supported 4G/3G/2G network
●5 x 10/100/1000M Ethernet LAN /WAN Ports (RJ45 Connector)
●1xUSB2.0 interface,1xRS232 port,1xRS485 port
●1xDI,1xDO
●1x CAN bus port
●2xNANO SIM card for 4G network
●4x4G modems
●48V POE output(optional)
●DC 10-36V power in
Parameters
|
Hardware |
||
|
CPU |
Qualcomm Quad-core CPU/ 1.8GHZ |
|
|
RAM |
8Gb |
|
|
eMMC |
4GB |
|
|
OS |
LINUX /OpenWRT |
|
|
SLK-R690-4G-A4(CN) |
4G/3G |
LTE-FDD B1/B3/B5 /B8 UMTS/HSPA+ B1/B8 |
|
SLK-R690-4G-A4(EU) |
4G/3G/2G |
LTE-TDD B38/B40/B41 LTE-FDD B1/B3/B5/B7/B8/B20 UMTS/HSPA+ B1/B5/B8 GSM/GPRS/EDGE B3/B8 |
|
SLK-R690-4G-A4(AU) |
4G/3G/2G |
LTE-TDD B40 LTE-FDD B1/B2/B3/B4/B5/B7/B8/B28 UMTS/HSPA+ B1/B2/B5/B8 GSM/GPRS/EDGE 850/900/1800/1900MHz |
|
SLK-R690-4G-A4(AF) |
4G/3G |
LTE Bands: B2/B4/B5/B12/B13/B14/B66/B71 WCDMA Bands: B2/ B4/ B5 |
|
SLK-R690-4G-A4(JP) |
4G/3G |
LTE FDD: Band1,3,8,11,18,19,21,26,28 LTE TDD: Band41 WCDMA/HSPA+: Band1,6,8,19 |
|
SLK-R690-4G-A4(LA) |
4G/3G/2G |
LTE FDD: Band 1,2,3,4,5,7,8,12,17,28,66 LTE TDD: Band 38,40 WCDMA/HSPA+: Band 1,2,3,4,5,8 GSM/GPRS/EDGE: 850/900/1800/1900MHz |
|
SLK-R690-4G-A4(ES) |
4G |
LTE-TDD:B45/61/59/62 B45/61:1.4G B59/62:1.8G TDD 1.8 GHz: 1785 to 1805 MHz TDD 1.4 GHz: 1447 to 1467 |
|
Bandwidth：100 Mbps(DL)/50 Mbps(UL) |
||
|
SLK-R690-4G-A4(EF) 600M |
4G |
LTE-TDD 600M 566 MHz - 626 MHz Channel 38650--39249 626 MHz - 678 MHz Channel 39650—40169 RX Sensitivity： (566 MHz - 626 MHz) <-101dBm@BW=20MHz (626 MHz - 678 MHz) <-100dBm@BW=20MHz TX24dBm，Level-2 Amplifier, supported 33dBm Bandwidth：110 Mbps(DL)/30 Mbps(UL) |
|
Bandwidth：110 Mbps(DL)/30 Mbps(UL) |
||
| SLK-R690-4G-A4(ED) 350M/450M | 4G |
LTE TDD：350/450M 380 MHz - 450 MHz 450MHZ 336 MHz - 346 MHz 350MHZ TX：23dBm,29dBm Max Level-2 Amplifier, supported 33dBm RX Sensitivity： 380 MHz - 450 MHz <-100dBm@BW=20MHz |
|
Bandwidth：110 Mbps(DL)/30 Mbps(UL) |
||
| Bandwidth |
LTE CAT4-DL：50Mbps, UL：150Mbps TD-HSDPA/HSUPA-DL：2.2 Mbps, UL：2.8 Mbps HSPA+-DL：5.76 Mbps, UL：42 Mbps
WCDMA – DL/UL：384Kbps |
|
|
Standalone GPS |
|
|
Multi-GNSS engine |
GPS, GLONASS, BeiDou, Galileo and QZSS |
|
LNA |
Built-in LNA for better sensitivity |
|
Supported Bands |
GPS L1 C/A: 1575.42 MHz Galileo E1: 1575.42 MHz QZSS L1: 1575.42 MHz GLONASS L1: 1602.5625 MHz BeiDou B1: 1561.098 MHz |
|
Channel |
Tracking: 48 Fast Acquisition: 2 |
|
Horizontal Position Accuracy |
Autonomous: < 1.5 m CEP |
|
Velocity Accuracy |
Without Aid: < 0.1 m/s |
|
Acceleration Accuracy |
Without Aid: < 0.1 m/s2 |
|
TTFF (without AGNSS) |
Cold Start: < 32 s Warm Start: < 25 s Hot Start: < 2 s |
|
Sensitivity |
Acquisition: -145 dBm Tracking: -162 dBm Reacquisition: -152 dBm |
|
Protocols |
NMEA 0183 |
|
WIFI supported |
|
|
Wireless |
High power WiFi performance On-board 2x2 2.4GHz 802.11b/g/n, max 21dBm per chain @-35dB DEVM On-board 2x2 5GHz 802.11a/n/ac/ax/max 20dBm per chain @-40dB DEVM |
|
Frequency |
2.412GHz to 2.472GHz and 5.150GHz to 5.825GHz, simultaneous dual band |
|
WIFI Rate |
2x2 MU-MIMO On-board WiFi 2.4GHz radio, up to 574Mbps physical data rate, TCP data up to 400Mbps |
|
2x2 MU-MIMO On-board WiFi 5GHz radio, up to 1201Mbps physical data rate, TCP data rate up to 800Mbps |
|
|
Modulation Techniques |
802.11b: DSSS (DBPSK / DQPSK / CCK) 802.11a/g: OFDM (BPSK / QPSK / 16-QAM / 64-QAM) 802.11ac/n: OFDM (BPSK / QPSK / 16-QAM / 64-QAM / 256-QAM) 802.11ax：OFDM 1024QAM |
|
Firewall |
Network Address Translation (NAT) DMZ Port Forwardin 1:1NAT |
|
State full Packet Inspection (SPI) |
|
|
Media Access Control |
CSMA/CA with ACK |
|
WiFi |
AP, Client |
|
VPN protocol |
PPTP,L2TP ,OpenVPN Client, IPsec，Wireguard |
|
DHCP |
Build-in DHCP (Dynamic Host Configuration Protocol) |
|
Others protocol |
Supported PPP,PPOE,DDNS,ICMP,VRRP etc |
| Device Manager | SNMP V1,V2,V3 TR069 |
|
Interface |
|
|
LAN/WAN Ports |
5x 10/100/1000M LAN/WAN ports(RJ45 Connector) VLAN,DHCP |
|
Serial Ports |
1x RS232 port (RJ45 connector) 1xRS485 port TCP server,TCP client,UDP,Modbus RTU to modbus TCP server 1xCan bus port(Optional) |
|
USB Port |
1x USB2.0 interface |
|
Reset |
1x Reset |
|
Antennas |
2x FAKRA WIFI Antennas interface (50Ω) 8x FAKRA 4G Antennas interface (50Ω) 1x FAKRA GPS Antennas interface |
|
LED |
Power-SYS-4G-Signal strength - LEDs |
|
SIM Card Slot |
4xSIM card slot ,supported e-SIM card |
|
POE Ethernet |
Supported 48V POE output(optional) |
|
Power interface |
|
|
Default power |
DC 12V/2A power adapter (US,EU etc stander option) |
|
Power connector |
GX12 3PIN（DC+，DC-，ACC power control） |
|
Input VDC |
10~36VDC |
|
Power Consumption |
24W (Max) |
|
Physical property |
|
|
Operating Temperature |
Storage Temperature: (-45°C to 85°C) |
|
Operating Temperature: (-40°C to 75°C) |
|
|
Relative Humidity |
95% |
|
Size |
L*S*H: 175*108*45 MM |
|
Weight |
Net weight:1.5KG |
|
Packing weight: 2KG |
|
|
Certification |
CCC,CE,FCC,RHOS |
|
Others |
|
|
2 years |
|
Order information
|
SLK-R690-4G-A4(CN) |
SLK-R690-4G-A4 CN bands 4G CPE , 2xWIFI antennas,2/4X 4G Antennas,1xGPS antenna (Optional) 1x 12V/2A Power adapter，1x RJ45 Cable 48V/3A Power adapter, When choose POE |
|
SLK-R690-4G-A4(EU) |
SLK-R690-4G-A1/A2(EU)4G CPE ,2xWIFI antennas, 2xWIFI antennas,2/4X 4G Antennas,1xGPS antenna (Optional) 1x 12V/2A Power adapter，1x RJ45 Cable 48V/3A Power adapter, When choose POE |
|
SLK-R690-4G-A4(AU) |
SLK-R690-4G-A4 AU bands 4G CPE ,2xWIFI antennas, 2xWIFI antennas,2/4X 4G Antennas,1xGPS antenna (Optional) 1x 12V/2A Power adapter，1x RJ45 Cable 48V/3A Power adapter, When choose POE |
|
SLK-R690-4G-A4(AF) |
SLK-R690-4G-A4 AF bands 4G CPE , 2xWIFI antennas, 2xWIFI antennas,2/4X 4G Antennas,1xGPS antenna (Optional) 1x 12V/2A Power adapter，1x RJ45 Cable 48V/3A Power adapter, When choose POE |
|
SLK-R690-4G-A4(JP) |
SLK-R690-4G-A4 JP bands 4G CPE ,2xWIFI antennas, 2xWIFI antennas,2/4X 4G Antennas,1xGPS antenna (Optional) 1x 12V/2A Power adapter，1x RJ45 Cable 48V/3A Power adapter, When choose POE |
|
SLK-R690-4G-A4(LA) |
SLK-R690-4G-A4 LA bands 4G CPE ,2xWIFI antennas, 2xWIFI antennas,2/4X 4G Antennas,1xGPS antenna (Optional) 1x 12V/2A Power adapter，1x RJ45 Cable
48V/3A Power adapter, When choose PO |
|
SLK-R690-4G-A4(ES) |
SLK-R690-4G-A4 ES bands 4G CPE,2xWIFI antennas, 2xWIFI antennas,2/4X 4G Antennas,1xGPS antenna (Optional) 1x 12V/2A Power adapter，1x RJ45 Cable
48V/3A Power adapter, When choose POE |
|
SLK-R690-4G-A4(EF) |
SLK-R690-4G-A4 EF bands 4G CPE,2xWIFI antennas, 2xWIFI antennas,2/4X 4G Antennas,1xGPS antenna (Optional) 1x 12V/2A Power adapter，1x RJ45 Cable
48V/3A Power adapter, When choose POE |
|
SLK-R690-4G-A4(EF) |
SLK-R690-4G-A4 ED bands 4G CPE,2xWIFI antennas, 2xWIFI antennas,2/4X 4G Antennas,1xGPS antenna (Optional) 1x 12V/2A Power adapter，1x RJ45 Cable
48V/3A Power adapter, When choose POE |
